Bullseye Calibrator pcb

[g6hfs]

Hi,

I tried g4eml gerber files but get errors with drill through hole file corrupted, are there any pcb’s out there to purchase or can someone supply kikad gerber zip file.

Brian
G6HFS

[g0mjw]

I have a design but got the FET pinout incorrect, it is through hole so easy to bend into place.


Mike

[g6hfs]

Hi Mike,

Yes thanks, that is no problem could you send a zip file please.

Email: brian@shawr.myzen .co.uk

73

Brian

[G1BVI]

I might have a spare blabk board at home.
If you can wait a few days I will look when I am home
73
Nick

[g6hfs]

Hi Nick,

Ok, I will hold off ordering.

Brian

[g4eml]

I have just rechecked them and the Gerber files on my GitHub are correct. They are the ones I used when I made the original batch of boards. So I don't know why your PCB supplier didn't like the files. I have used PCBWAY or JLCPCB without any issues.

I use Eagle not Kicad so my source file won't be of any use to you.



Colin G4EML.

[G1BVI]

Found a couple
Pm me your address please and I'll get it in post tomorrow
73
Nick

Ps its through hole version.

[g6hfs]

Hi Nick,

Will do, 1 will be good thanks.

Brian
